Sorting Algorithms
Working with Data Structures and manipulating data.
import random
numbers = []
for i in range(10):
numbers.append(random.randint(0,100))
print("Random List")
print(numbers)
Explore
Get into groups of 3
We will be focusing on 4 algorithms today.
We will look at the first one together, Bubble Sort
What is happening with this sort?
In your groups you will each choose to be an expert on a sorting algorithm. Merge, Selection, and Insertion. Take about 5 minutes to read about your algorithm (Geek for Geeks linked below) and be ready to explain it to your other group members.
Practice 1
[75, 17, 46, 80, 67, 45, 69, 79, 40, 0]
How would you sort this list with...
- Bubble Sort
Bubble Sort works by repeatedly swapping adjacent elements if they are in the wrong order. It continues iterating through the list until the entire list is sorted.
Here's how the sorting process would unfold for the given list:
Pass 1: [17, 46, 75, 67, 45, 69, 79, 40, 0, 80]
Pass 2: [17, 46, 67, 45, 69, 75, 40, 0, 79, 80]
Pass 3: [17, 46, 45, 67, 69, 40, 0, 75, 79, 80]
Pass 4: [17, 45, 46, 67, 40, 0, 69, 75, 79, 80]
Pass 5: [17, 45, 46, 40, 0, 67, 69, 75, 79, 80]
Pass 6: [17, 45, 40, 0, 46, 67, 69, 75, 79, 80]
Pass 7: [17, 40, 0, 45, 46, 67, 69, 75, 79, 80]
Pass 8: [17, 0, 40, 45, 46, 67, 69, 75, 79, 80]
Pass 9: [0, 17, 40, 45, 46, 67, 69, 75, 79, 80]
After nine passes, the list is sorted in ascending order using Bubble Sort.
- Selection Sort
Selection Sort works by repeatedly finding the minimum element from the unsorted part of the list and placing it at the beginning. It divides the list into two parts: sorted and unsorted. Here's how the sorting process would unfold for the given list:
Pass 1: [0, 17, 46, 80, 67, 45, 69, 79, 40, 75]
Pass 2: [0, 17, 40, 80, 67, 45, 69, 79, 46, 75]
Pass 3: [0, 17, 40, 45, 67, 80, 69, 79, 46, 75]
Pass 4: [0, 17, 40, 45, 46, 80, 69, 79, 67, 75]
Pass 5: [0, 17, 40, 45, 46, 67, 69, 79, 80, 75]
Pass 6: [0, 17, 40, 45, 46, 67, 69, 75, 80, 79]
Pass 7: [0, 17, 40, 45, 46, 67, 69, 75, 79, 80]
After seven passes, the list is sorted in ascending order using Selection Sort.
Practice 2
[88, 39, 53, 39, 58, 43, 74, 81, 71, 51]
How would you sort this list with...
- Merge Sort
Merge Sort is a divide-and-conquer algorithm that recursively divides the list into smaller halves, sorts them individually, and then merges them back together to obtain the final sorted list. Here's how the sorting process would unfold for the given list:
Step 1: Divide the list into individual elements [88], [39], [53], [39], [58], [43], [74], [81], [71], [51]
Step 2: Merge the individual elements pairwise [39, 88], [39, 53], [39, 53, 88], [39, 39, 53, 53, 88], [43, 58], [43, 58, 74], [43, 58, 74, 81], [51, 71], [51, 71, 81], [51, 71, 74, 81]
Step 3: Merge the pairs until we obtain the final sorted list [39, 39, 53, 53, 58, 88], [43, 58, 74, 74, 81], [51, 71, 71, 81]
Final sorted list: [39, 39, 43, 51, 53, 53, 58, 71, 74, 74, 81, 81, 88]
- Insertion Sort
Insertion Sort works by dividing the list into sorted and unsorted portions. It iterates over each element in the unsorted portion and inserts it into the correct position in the sorted portion.
Pass 1: [39, 88, 53, 39, 58, 43, 74, 81, 71, 51]
Pass 2: [39, 53, 88, 39, 58, 43, 74, 81, 71, 51]
Pass 3: [39, 39, 53, 88, 58, 43, 74, 81, 71, 51]
Pass 4: [39, 39, 53, 58, 88, 43, 74, 81, 71, 51]
Pass 5: [39, 39, 43, 53, 58, 88, 74, 81, 71, 51]
Pass 6: [39, 39, 43, 53, 58, 74, 88, 81, 71, 51]
Pass 7: [39, 39, 43, 53, 58, 74, 81, 88, 71, 51]
Pass 8: [39, 39, 43, 53, 58, 71, 74, 81, 88, 51]
Pass 9: [39, 39, 43, 53, 58, 71, 74, 81, 88, 51]
Pass 10: [39, 39, 43, 51, 53, 58, 71, 74, 81, 88]
import nltk
import random
nltk.download('words') # Download the word list (only required once)
from nltk.corpus import words
english_words = words.words()
#print(len(english_words)) # Prints the number of words in the list
# You can now use the 'english_words' list in your code
words = []
for i in range(10):
words.append(english_words[random.randint(0,len(english_words))])
print("Random List")
print(words)
Using Merge Sort
def merge_sort(arr):
if len(arr) <= 1:
return arr
mid = len(arr) // 2
left_half = arr[:mid]
right_half = arr[mid:]
left_half = merge_sort(left_half)
right_half = merge_sort(right_half)
return merge(left_half, right_half)
def merge(left, right):
merged = []
left_index = 0
right_index = 0
while left_index < len(left) and right_index < len(right):
if left[left_index].lower() < right[right_index].lower():
merged.append(left[left_index])
left_index += 1
else:
merged.append(right[right_index])
right_index += 1
while left_index < len(left):
merged.append(left[left_index])
left_index += 1
while right_index < len(right):
merged.append(right[right_index])
right_index += 1
return merged
words = ['criniferous', 'logie', 'relatedness', 'prestidigital', 'Shirvan', 'ineducabilian', 'opiliaceous', 'undiscriminated', 'ballooner', 'treadmill']
sorted_words = merge_sort(words)
print("unsorted:")
print(words)
print()
print("sorted:")
print(sorted_words)
Discuss
Answer the following with your group.
- When should you use each algorithm? What makes an algorithm the right choice?
- Given the following lists...
- [0, 2, 6, 4, 8, 10]
- [Elephant, Banana, Cat, Dog, Apple]
- [29, 13, 83, 47, 32, 78, 100, 60, 65, 15, 24, 9, 40, 68, 53, 8, 90, 58, 39, 32, 34, 91, 74, 94, 49, 87, 34, 87, 23, 17, 27, 2, 38, 58, 84, 15, 9, 46, 74, 40, 44, 8, 55, 28, 81, 92, 81, 88, 53, 38, 19, 21, 9, 54, 21, 67, 3, 41, 3, 74, 13, 71, 70, 45, 5, 36, 80, 64, 97, 86, 73, 74, 94, 79, 49, 32, 20, 68, 64, 69, 1, 77, 31, 56, 100, 80, 48, 75, 85, 93, 67, 57, 26, 56, 43, 53, 59, 28, 67, 50] Select the algorithm you believe is best for each, explain.
HACKS
Provided below is a Bubble Sort Algorithm sorting a list of dictionaries based off of selected key.
-
Now it's time to do some coding...
-
Run code and then research and answer these questions...
-
Is a list and/or dictionary in python considered a primitive or collection type? Why?
A list and dictionary are both considered collection types in python. Primitive types are integers, strings, booleans, and cannot hold and organize multiple values or objects.
-
Is the list passed into bubble sort "pass-by-value" or "pass-by-reference? Describe why in relation to output.
The list passed into bubble sort is passed by reference. This means that the actual list object is being modified within the function, and any changes made to the list will be reflected outside the function as well.
-
-
Implement new cell(s) and/or organize cells to do the following.
- Create your own list
- Use your expertise sorting algorithm (selection, insertion, merge). Note, I got my bubble sort from Geek for Geeks and made modifications. Each student in a group should have a unique algorithm.
- Test your list with my bubble sort
- Test my list with your new sort
- Research analysis on sorting:comparisons, swaps, time. Build this into your hacks. - Find a better way to print the data, key first, then other elements in viewable form.
Use the code below to help guide your adventure
"""
* Creator: Nighthawk Coding Society
Bubble Sort of a List with optimizations
"""
# bubble sorts a list of dictionaries, base off of provided key
def bubbleSort(list, key):
n = len(list) - 1 # list are indexed 0 to n-1, len is n
# Traverse through list with i index
for i in range(n):
swapped = False # optimize code, so it exits if now swaps on inner loop
# Inner traversal using j index
for j in range(n-i): # n-i as positions on right are in order in bubble
# Swap if the element KeyN is greater KeyN1
keyN = list[j].get(key)
keyN1 = list[j+1].get(key)
if keyN > keyN1:
swapped = True
list[j], list[j + 1] = list[j + 1], list[j] # single line swap
if not swapped: # if no swaps on inner pass, list is sorted
return # exit function
if __name__ == "__main__":
# list/dictionary sample
list_of_people = [
{"name": "taylor swift", "age": 33, "album": "folklore"},
{"name": "harry styles", "age": 29, "album": "fine line"},
{"name": "gracie abrams", "age": 23, "album": "good riddance"},
]
# assuming uniform keys, pick 1st row as source of keys
key_row = list_of_people[0]
# print list as defined
print("original")
print(list_of_people)
for key in key_row: # finds each key in the row
print(key)
bubbleSort(list_of_people, key) # sort list of people
print(list_of_people)
Merge Sort
def mergeSort(arr, key):
if len(arr) <= 1:
return arr
mid = len(arr) // 2
left = arr[:mid]
right = arr[mid:]
left = mergeSort(left, key)
right = mergeSort(right, key)
return merge(left, right, key)
def merge(left, right, key):
merged = []
i = j = 0
while i < len(left) and j < len(right):
if left[i].get(key) <= right[j].get(key):
merged.append(left[i])
i += 1
else:
merged.append(right[j])
j += 1
while i < len(left):
merged.append(left[i])
i += 1
while j < len(right):
merged.append(right[j])
j += 1
return merged
if __name__ == "__main__":
# list/dictionary sample
list_of_people = [
{"name": "taylor swift", "age": 33, "album": "folklore"},
{"name": "harry styles", "age": 29, "album": "fine line"},
{"name": "gracie abrams", "age": 23, "album": "good riddance"},
]
# assuming uniform keys, pick the first row as the source of keys
key_row = list_of_people[0]
# print the list as defined
print("original")
print(list_of_people)
for key in key_row: # find each key in the row
print(key)
sorted_list = mergeSort(list_of_people, key) # sort the list of people
print(sorted_list)
Comparison: In the merge sort algorithm, comparisons are used to determine the relative order of elements during the merging process. The comparisons are performed based on a specified key or attribute of the elements being sorted.
Swaps: In the merge sort algorithm, swaps are not directly used to reorder elements. Instead, the merging process in merge sort involves creating new lists or arrays to store the sorted elements. The elements from the original list are selectively placed in the appropriate positions in the new merged list.
Time: Estimate of how the algorithm's performance scales with the input size. Merge sort has a time complexity of O(n log n), where n is the number of elements in the list. This means that as the list size doubles, the time taken to sort it will increase by a factor of approximately two times the logarithm of the list size.
Better way of printing data:
def mergeSort(arr, key):
if len(arr) <= 1:
return arr
mid = len(arr) // 2
left = arr[:mid]
right = arr[mid:]
left = mergeSort(left, key)
right = mergeSort(right, key)
return merge(left, right, key)
def merge(left, right, key):
result = []
i = j = 0
while i < len(left) and j < len(right):
if left[i][key] <= right[j][key]:
result.append(left[i])
i += 1
else:
result.append(right[j])
j += 1
result.extend(left[i:])
result.extend(right[j:])
return result
if __name__ == "__main__":
list_of_people = [
{"name": "taylor swift", "age": 33, "album": "folklore"},
{"name": "harry styles", "age": 29, "album": "fine line"},
{"name": "gracie abrams", "age": 23, "album": "good riddance"},
]
key_row = list_of_people[0]
print("Original:")
for person in list_of_people:
print(person)
print("\nSorted by Name:")
sorted_list = mergeSort(list_of_people, "name")
for person in sorted_list:
print(person)
print("\nSorted by Age:")
sorted_list = mergeSort(list_of_people, "age")
for person in sorted_list:
print(person)
print("\nSorted by Album:")
sorted_list = mergeSort(list_of_people, "album")
for person in sorted_list:
print(person)
